Ferrofish Verto 64

64 channel ADAT <> Dante format converter
Manufacturer: Ferrofish
SKU: Verto64
GTIN: 4313042884023
$1,199.00

Dantify your equipment. All of it!

The VERTO64 is a high-quality solution to connect a wide range of ADAT equipment to a Dante/AES67 network with up to 96 kHz. The ultra-compact device is an easy way, to enable Dante connectivity to an existing live or studio setup.

The VERTO64 provides 8 ADAT I/Os – each with 8 channels – for 64 x 64 channel operation. The converter features an additional Word Clock I/O and is easily remote controlled via the network connection and MIDI.

Thanks to the array of 16 “Lightpipe” connections, the VERTO64 can integrate several studio devices or a loaded stage box into the Dante network. It can simply turn ADAT-equipped devices, like the RME Firefaces or DIGIface, into fully functional Audio-over-IP computer interfaces.

Connected to a Dante network, the VERTO64 is immediately detected with all 128 I/Os and automatically configured. This way every room with a LAN connection can be used for recording or mixing – simply plug the device into the network and start to work – with full Dante fail-safe Two-Port-Redundancy.

Thanks to the small footprint, any Verto converter fits easily into mobile setups and can be always carried as Dante connection kit for complete stage boxes.

An additional rack mount kit is available.

Ferrofish offers a feature-identical version with 32 ADAT I/Os: VERTO32



VERTO 32 / VERTO 64

Specifications

Dante I/O
  • 2x RJ-45 Ethernet port (PRIMARY/SECONDARY), 1 GBit Network
  • 64 x 64 channel I/O (Dante Brooklyn II board built-in)

ADAT I/O

VERTO 32: 4x ADAT Input + 4x ADAT Output, optical TOSLINK

Channel count:
  • 32x32 channels at 48kHz,
  • 16x16 channels at 96kHz

VERTO 64: 8x ADAT Input + 8x ADAT Output, optical TOSLINK

Channel count:
  • 32x32 channels at 48kHz
  • 16x16 channels at 96kHz

MIDI I/O

  • 2 x DIN5 connector for MIDI embedding/de-embedding

Wordclock I/O

  • BNC: 1 x input, 1 x output
  • 75 Ohm Termination set by default (switchable via Dante)

Power Supply

14.4VA (1.2A at 12V)

  • Polyfuse internal, self-resetting
  • 1 x power supply included

Operation

  • Temperature range: 41°F up to 113°F (+5°C up to +45°C)
  • Humidity: <75%, non-condensing

Weight/Size

  • Weight: 0,9 kg
  • Dimensions: 22 x 9 x 4,5 mm (without rack ears)

Optional accessories

  • 19“ Rack mountain kit, metal (for mounting 1 x Verto in a 19” rack-space)
  • Multi-range Power Supply 12V (EU)
  • ADAT Cable Locking Plate (Part. No. 7027)

Dantify your equipment. All of it!

The VERTO64 is a high-quality solution to connect a wide range of ADAT equipment to a Dante/AES67 network with up to 96 kHz. The ultra-compact device is an easy way, to enable Dante connectivity to an existing live or studio setup.

The VERTO64 provides 8 ADAT I/Os – each with 8 channels – for 64 x 64 channel operation. The converter features an additional Word Clock I/O and is easily remote controlled via the network connection and MIDI.

Thanks to the array of 16 “Lightpipe” connections, the VERTO64 can integrate several studio devices or a loaded stage box into the Dante network. It can simply turn ADAT-equipped devices, like the RME Firefaces or DIGIface, into fully functional Audio-over-IP computer interfaces.

Connected to a Dante network, the VERTO64 is immediately detected with all 128 I/Os and automatically configured. This way every room with a LAN connection can be used for recording or mixing – simply plug the device into the network and start to work – with full Dante fail-safe Two-Port-Redundancy.

Thanks to the small footprint, any Verto converter fits easily into mobile setups and can be always carried as Dante connection kit for complete stage boxes.

An additional rack mount kit is available.

Ferrofish offers a feature-identical version with 32 ADAT I/Os: VERTO32



VERTO 32 / VERTO 64

Specifications

Dante I/O
  • 2x RJ-45 Ethernet port (PRIMARY/SECONDARY), 1 GBit Network
  • 64 x 64 channel I/O (Dante Brooklyn II board built-in)

ADAT I/O

VERTO 32: 4x ADAT Input + 4x ADAT Output, optical TOSLINK

Channel count:
  • 32x32 channels at 48kHz,
  • 16x16 channels at 96kHz

VERTO 64: 8x ADAT Input + 8x ADAT Output, optical TOSLINK

Channel count:
  • 32x32 channels at 48kHz
  • 16x16 channels at 96kHz

MIDI I/O

  • 2 x DIN5 connector for MIDI embedding/de-embedding

Wordclock I/O

  • BNC: 1 x input, 1 x output
  • 75 Ohm Termination set by default (switchable via Dante)

Power Supply

14.4VA (1.2A at 12V)

  • Polyfuse internal, self-resetting
  • 1 x power supply included

Operation

  • Temperature range: 41°F up to 113°F (+5°C up to +45°C)
  • Humidity: <75%, non-condensing

Weight/Size

  • Weight: 0,9 kg
  • Dimensions: 22 x 9 x 4,5 mm (without rack ears)

Optional accessories

  • 19“ Rack mountain kit, metal (for mounting 1 x Verto in a 19” rack-space)
  • Multi-range Power Supply 12V (EU)
  • ADAT Cable Locking Plate (Part. No. 7027)
