WHAT IS AN SDI PTZ CAMERA?
SDI REFERS TO SERIAL DIGITAL INTERFACE, A STANDARD FOR THE DELIVERY OF DIGITAL VIDEO VIA A COAXIAL CABLE. THE SDI STANDARD HAS BEEN WIDELY ADOPTED BY THE BROADCAST INDUSTRY TO TRANSMIT UNCOMPRESSED, UNENCRYPTED DIGITAL VIDEO SIGNALS.
BUILD YOUR PTZ CAMERA SYSTEM
OUR SDI LINE INCLUDES SOME OF THE MOST POPULAR CAMERA MODELS WE’VE EVER MADE. WITH GAME-CHANGING OPTICS AND HIGH-QUALITY VIDEO OUTPUTS, VIDEO PROFESSIONALS CAN CREATE INNOVATIVE CUSTOM SYSTEMS TO UNIQUELY SUIT THEIR NEEDS.
OUR MULTIPLE VIDEO OUTPUTS AND CONTROL METHODS ACCOMMODATE THE GROWING DEMANDS OF MODERN VIDEO PRODUCTION.
DISCREET MOUNTING OPTIONS
MOUNT YOUR PTZ CAMERA ABOVE, BELOW OR BESIDE THE ACTION TO CAPTURE THE IDEAL VIEW EVERY TIME.
VERSATILE CONTROL OPTIONS
REMOTE CAMERA CONTROL OPTIONS WHEN AND WHERE YOU WANT THEM. USE PTZ CONTROLS BUILT-IN TO YOUR FAVORITE VIDEO PRODUCTION SOFTWARE SUCH AS OBS, LIVESTREAM STUDIO, WIRECAST, VMIX, MIMOLIVE OR TRICASTER. OR CHECK OUT ONE OF OUR HARDWARE JOYSTICK CONTROLLERS SUCH AS OUR IP JOYSTICK, SERIAL JOYSTICK, OR THE SUPERJOY. TRY OUR FREE IP CONTROL APPLICATION FOR MAC OR PC, OUR OPEN-SOURCE CONTROL SOFTWARE ON GITHUB, AND OUR OBS PLUGIN HERE. MOBILE DEVICE CONTROL OPTIONS ARE AVAILABLE HERE.
FEATURES AND BENEFITS
WIDE DYNAMIC RANGE: HELPS WITH CHALLENGING LIGHTING CONDITIONS SUCH AS A MIX OF DARK AND LIGHT AREAS
NOISE REDUCTION: 2D AND 3D NOISE REDUCTION WITH OUR LATEST “LOW NOISE CMOS SENSOR”
FULL FRAME RATES: 1080P-60/50/30/25, 1080-60/50, 720P-60/50/30/25
WARRANTY: 5 YEAR PARTS & LABOR MANUFACTURER WARRANTY
BROADCAST FRAME RATES: 1080P59.94/29.97, 1080I59.94, 720P59.94
ADVANCED WHITE BALANCE MODES: SIMPLE ONE-PUSH & NEW KELVIN TEMPERATURE SCALE
Rear Board Connectors
Video Output Interface HDMI, 3G-SDI, IP Streaming, CVBS
Lens Zoom 30x
Power Supply Interface JEITA type Power Adapter (DC IN 12V)
Network Interface RJ45
Audio Interface Line In, 3.5mm (HDMI & IP Stream Only)
Communication Interface RS-232, RS485, PELCO-D/P
Baud Rate 2400/4800/9600 bits
3G-SDI Interface BNC – 75 Ohm, Female
USB 2.0 Interface Future Use
Camera & Lens
Video Sensor 1/2.7” CMOS, 2.07 Mega Pixels
Frame Rates 1080p-60*/50/30/25, 1080i-60*/50, 720p-60/50/30/25
Frame Rates (CVBS) 576i/30, 480i/30
Focal Length F4.42mm-132.6mm, F1.8-F2.8
Field of View 60.7°
Min Lux 0.5 Lux at F1.8, AGC ON
Shutter Speed 1/30s - 1/10000s
SNR ≥55dB
Vertical Flip & Mirror Supported
Horizontal Angle of View 2.28° (tele) to 60.7° (wide)
Vertical Angle of View 1.28° (tele) to 34.1°(wide)
Working Environment Indoor
Physical Specification
Dimension (in.) 5.6W x 6.5H x 6.7D (7.8H max w/ Tilt)
Dimensions (mm) 142W x 164H x 169D (198H max w/ Tilt)
Box Dimensions 9” x 9” x 10” | 229mm x 254mm x 229mm
Camera Weight 3.10 lbs. (1.41 kg)
Boxed Weight 5.4 lbs. (2.45 kg)
Pan & Tilt Movement
