Includes 1TB NMVe SSD
Thunderbolt 3 Dock
Designed to sit at the center of your creative universe.
Glyph’s Thunderbolt 3 dock delivers more ports, more power, and more storage at the fastest speeds possible.The only Thunderbolt 3 Dock that matters.Whether you're looking to simplify your workstation setup or you're a DIT looking to streamline your cart, Glyph's Thunderbolt 3 Dock gives you all the ports you need with the option to add an NVMe SSD (user-upgradeable). Enclosed in a rugged aluminum frame and built to last.
Specs -
Thunderbolt 3, 40Gbps (x2)
Displayport 1.2 (x1) *
SD (UHS-II) (x1)
USB 3.0 type-A (x2)
USB 3.1 Gen2, typce-C (x1)
M.2 socket for NVMe SSD (x1)
Audio out (x1)
Mic out (x1)
1Gb Ethernet (x1)
* In order to use the Dock display port with another protocol,
like HDMI, the cable or adapter has to be active; the Dock is
not display port++, and will not adapt the protocol.
Features
Supports:
Single 5k display @ 60Hz (5120x2880)
Dual 4K displays @ 60Hz
Supports 87W power delivery
SD (UHS-II) speeds up to 270MB/s
USB 3.0 type-A supports 5Gbps / 5V @ 1.2A
USB 3.0 type-C supports PD 5V @ 3A
M.2 socket supports PCI-e Gen.3 x2
Transfer Rate
NVMe SSD speeds up to 1,500 MB/s
Compatibility
Mac OS 10.X or above
Windows 10 or later
Computer with Thunderbolt 3 port
Cooling
Passive heat dissipation
Dimensions
9.4" x 3.75" x 0.9" in
In the box
Thunderbolt 3 Dock
Thunderbolt 3, 40Gbps cable
87W power supply
