Blackmagic Pocket Cinema Camera 4K & Azden PRO XR Kit
- BMD-CINECAMPOCHDEF6K Blackmagic Pocket Cinema Camera 6K
- AZDEN-PRO-XR 2.4GHz digital wireless mic system w/ signal redundancy
- AZDEN-MX-M1 3.5mm male TRS to mini-XLR male cable
MX-M1 3.5mm Male TRS to Mini-XLR Male Cable
- 3.5mm TRS Male to 3-pin mini-XLR Male
- Adapts unbalanced mini-jack (3.5mm) audio output to balanced mini-XLR input
- Intended for cameras with mini-XLR input such as BMPCC4K & 6K as well as Canon C70
Connect your Azden microphone or wireless receiver to the pro-level Mini XLR audio input available on some small format cameras, such as the Blackmagic Pocket Cinema Camera 4K or 6K, with this male 3.5 mm TRS to male 3-pin Mini XLR adapter cable. Designed to adapt any unbalanced “dual-mono” mini-jack microphone output to a balanced Mini XLR input. The MX-M1 is compatible with all Azden single-channel wireless receivers.
This cable is not suitable for true stereo outputs with distinct left & right audio signals.
Compatible with all single-channel Azden wireless receivers, including PRO-XR, PRO-XRe and PRO-XD.
Azden PRO-XR 2.4GHz Digital Wireless Mic System with Signal Redundancy
- For digital cameras and mobile devices
- Proprietary digital technologies avoid 2.4 GHz interference • Adjustable transmitter output power
- External antenna design for better performance
- Up to 500’ range
- Includes high-quality lavalier microphone
- Includes smartphone mount
- Rechargeable lithium-ion batteries
- Runtime up to 20 hours on RX and 14 hours on TX
- Six-step adjustable output gain
- Headphone and microphone outputs / Line-in auxiliary input • 1/4”-20 threaded shoe mount on receiver
- 2-year warranty with online registration
The PRO-XR uses newly developed and proprietary technology to make an extremely reliable and robust wireless connection in the 2.4 GHz spectrum. Avoiding the common pitfalls in this crowded frequency spectrum, the system uses data stream redundancy and an advanced frequency hopping algorithm to avoid interference and dropouts. The result is a 2.4 GHz wireless kit that is dependable enough for use by professionals.
In keeping with its “professional grade” moniker, the PRO-XR will come with a professional quality lavalier microphone and will be able to deliver pro-level sound quality.
Transmitter and receiver units are compact, weighing just about 2.5 oz each, with incorporated lithium-ion rechargeable batteries that promise up to 16 hours of continuous usage on a full charge.
The receiver unit will have a standard size accessory shoe for camera-top mounting, but also a 1/4″-20 female thread for boom-pole and camera cage mounting.
The PRO-XR package will include a number of accessories to make it compatible with mobile video shooting right out of the box: a mini-tripod/mobile grip, a clamp-style phone mount with accessory shoe mount, a traditional TRRS adapter cable for smartphones and tablets, and a Lightning-to-headphone adapter for iOS mobile devices without a headphone jack.
Blackmagic Design Pocket Cinema Camera 4K
Announcing the all Blackmagic Pocket Cinema Camera 4K, a handheld digital film camera with full 4/3 HDR sensor, dual native ISO with up to 25600 ISO for incredible low light performance as well as 13 stops of dynamic range. It also eliminates expensive external recorders, as it features a unique new USB-C Expansion Port, which allows customers to record using the internal SD/UHS-II and CFast recorders or directly to the same external disks they will use for editing and color correction.
The revolutionary Blackmagic Pocket Cinema Camera 4K is the handheld digital film camera that customers have been asking for. It packs incredibly high end imaging and professional features into a portable and affordable design that can be used anywhere. The compact body style is perfect for shooting independent films and documentaries, fashion shows, travel blogs, web videos, weddings, corporate video, sports and much more.
The Blackmagic Pocket Cinema Camera 4K features a full size 4/3 HDR sensor with native 4096 x 2160 resolution and 13 stops of dynamic range for true digital film quality. The full size of the 4/3 sensor is designed to perfectly match MFT lenses so the crop factor is greatly reduced, giving customers a wider field of view. It also features dual native ISO with up to 25600 ISO for incredible low light performance.
The Blackmagic Pocket Cinema Camera 4K is packed with features such as a MFT lens mount, large 5 inch touchscreen monitor, 10-bit ProRes and 12-bit RAW recording, 3D LUTs, 4 built in microphones, mini XLR audio input with phantom power, Bluetooth wireless camera control, HDMI on set monitoring output and more. The latest Blackmagic Design color science lets customers shoot images that are far better than DSLR cameras and even better than professional digital film cameras costing tens of thousands more.
Designed using a space age carbon fiber polycarbonate composite, the body of the Blackmagic Pocket Cinema Camera 4K is extremely strong and light. The carbon composite material consists of a high strength polymer that’s reinforced with carbon fibers. This gives the camera body incredible strength and rigidity to help protect it from accidental knocks and drops which can often result in damage. The handheld design features a multi function grip which has logically placed buttons and dials that allow super fast access to essential shooting functions such as recording start/stop, still photos, ISO, shutter, aperture, white balance, power and more.
Fourth generation Blackmagic Design color science lets customers shoot HDR images in film, video and new extended video modes. The new extended mode combines the latitude of digital film with an optimized video file. This gives customers working on fast turnaround projects an ideal solution for shooting great looking images that don’t need a lot of color correction or post production work.
Images can be recorded onto standard SD cards, faster UHS-II cards or CFast 2.0 cards in either ProRes or RAW formats. The Blackmagic Pocket Cinema Camera 4K can record 4K images at up to 60 frames per second and windowed HD at up to 120 frames per second. It’s also the first camera that lets customers record directly onto the same exact external USB-C media drives they use for editing and color correction. That means customers can turn projects around much more quickly because they don’t have to transfer files. All they need to do is unplug the USB-C drive and then connect it to their computer to start editing.
The Blackmagic Pocket Cinema Camera 4K uses the same MFT (Micro Four Thirds) lens mount as the original Pocket Cinema Camera so customers can use the investment in lenses they already own. The MFT mount is extremely flexible and allows for different lens adapters so customers can also use PL, C, EF and other types of lenses from manufacturers such as Canon, Nikon, Pentax, Leica and even Panavision.
The rear of the camera features a large bright 5 inch touchscreen that makes it easy to frame shots and accurately focus. It also uses the same Blackmagic OS as URSA Mini so customers can use simple tap and swipe gestures to adjust settings, add metadata and view recording status. On screen overlays make it easy to see recording parameters, status, histogram, focus and peaking indicators, and playback controls. In addition, 3D LUTs can be applied for both monitoring and recording.
For audio, the Blackmagic Pocket Cinema Camera 4K features multiple built in microphones with an extremely low noise floor, a mini XLR input with 48 volts of phantom power to connect professional lapel and boom mics, and a 3.5mm stereo audio jack for connecting different types of video camera microphones. The high quality built in audio recording means customers don’t have to carry around a separate recorder.
The Blackmagic Pocket Cinema Camera 4K also includes a full size HDMI connector which can output HDR video as well as a clean 10-bit video feed with optional on screen overlays. There’s also an innovative high speed USB-C Expansion Port for adding external accessories such as flash drives and an SSD for external recording. The camera uses standard LP-E6 batteries and can be charged via USB-C or the locking DC power connector, which protects the camera from being accidentally unplugged during a shoot.
“Customers love the original Blackmagic Pocket Cinema Camera and have been asking us for a 4K version,” said Grant Petty, Blackmagic Design CEO. “We’ve listened and built a camera that combines all of our newest ideas and customer feedback from the previous model! The Blackmagic Pocket Cinema Camera 4K is exciting because it packs so much technology into an incredibly small design. We feel it will go well beyond what customers expected. It’s perfect for anyone that needs a truly professional ultra compact digital film camera. This is not a consumer camera that's trying to do high end work, it’s a true high end camera designed for high end work.”
Blackmagic Pocket Cinema Camera 4K Features
- Full size 4/3 sized sensor with native 4096 x 2160 resolution sized sensor.
- Compatible with extremely high quality Micro Four Thirds lenses.
- Super wide 13 stops of dynamic range allows capture for high end feature film look.
- Up to 25600 ISO for incredible low light performance.
- Carbon fiber polycarbonate composite body which makes it lightweight, portable and durable.
- Multi function grip for quick access to recording start/stop, still photos, ISO, shutter, aperture, white balance, power and more.
- Built in SD, UHS-II and CFast card recorders.
- USB-C expansion port allows longer duration recording directly to an external SSD or flash disk.
- Standard open file formats compatible with popular NLE software such as 10-bit ProRes and 12 bit RAW.
- Features full size HDMI output for monitoring with camera status graphic overlay.
- Professional mini XLR input with 48 volts of phantom power for connecting to pro microphones.
- 3.5mm audio jack, headphone jack, and locking DC 12 volt power connection.
- Built in 5” LCD touchscreen allows accurate focus when shooting 4K.
- LCD supports on screen overlays including status, histogram, focus peaking, and transport controls.
- Records 4K images at up to 60 frames per second and windowed HD at up to 120 frames per second.
- 3D LUTs can be applied for both monitoring and recording.
- Blackmagic OS as used in URSA Mini and URSA Broadcast cameras.
- 4th generation Blackmagic color science.
- Supports remote camera control via Bluetooth.
- Includes full license for DaVinci Resolve Studio editing, color, visual effects and audio post production.
