Angelbird AV PRO CF XT 512 GB

Angelbird AVpro CF XT 512 GB

GENERAL SPECIFICATIONS

Capacity

256GB | 512GB

Dimensions

42.8 x 36.4 x 3.3 mm

(1.69 × 1.43 × 0.13 in)

Form Factor

CFast

Weight

~ 10.0 g

TECHNICAL SPECIFICATIONS

Interface

CFast 2.0 3SATA 3.1 compliant

Over provisioning

~ 13 %

Features

Temperature sensor, TRIM, ECC, EMS protection, built-in cache, SMART

PERFORMANCE SPECIFICATIONS

Sustained Read Speed

Up to 550 MB/s

Sustained Write Speed

Up to 480 MB/s

RELIABILITY SPECIFICATIONS

MTBF

> 2,000,000 hours

Data Reliability

Built-in EDC / ECC function

Data Retention

10 years at 25°C

Certifications

RoHS, CE, FCC

ELECTRICAL SPECIFICATIONS

DC input voltage

3.3V ± 5%

Power usage (idle/max)

0.35W / 2.55W

ENVIRONMENTAL SPECIFICATIONS

Shock resistance (operating)

50G

Vibration resistance (operating)

3.1G

Operating Temperature

0 °C ~ +70 °C

Storage Temperature

–40 °C ~ +85 °C

Operating Humidity

5 % to 95 % non-condensing

COMPATIBILITY LIST

• Atomos

• Blackmagic Design

• Phantom

• Canon

• Hasselblad

WARRANTY

3-year limited warranty

PACKAGE CONTENT

• SSD AV PRO CF XT

• Safety pouch

• Activation code for the full limited

• warranty and additional free software

• licenses and content
